NZ 240-260 Technical data, dimensions
You are here: / Start / Products / Turnkey stations / SCHEIDT System NZ / NZ 240-260 Technical data, dimensions
SCHEIDT SYSTEM NZ
Non-walk-in stations, cell construction
The SCHEIDT SYSTEM NZ 240-260 in detail.
Technical data:
SCHEIDT SYSTEM NZ 240-260
| Rated capacity: | max. 1600 kVA¹ | |
| External dimensions: | ||
| W: 2.40 m | L: 2.60 m | H: 2.71 m |
| Dimensions inside: | ||
| W: 2.17 m | L: 2.37 m | H: 2.44 m |
| Total weight empty:² | about 8.33 t | |
| Roof weight: | about 2.05 t | |
| Built-up area: | 6.24 m² | |
| Constructed space: | 16.91 m³ | |
| Effective area: | 5.14 m² | |
| Station stop: | Rd30 | |
| Roof anchorage: | Rd16 | |
| Standard door dimensions | Light door dimension | Light door dimension |
| Standard dimensions | Steel doors | Aluminum doors |
| W: 2155 x H: 1320 mm | W: 2065 x H: 1230 mm | W: 2095 x H: 1185 mm |
| W: 1100 x H: 1320 mm | W: 1030 x H: 1230 mm | W: 1055 x H: 1185 mm |
¹ Installed rated capacity depending on the transformer losses
and the ventilation technology used.
² Empty weight depending on the station structure.
