Because your world is also ours

SCHEIDT- References

Supply stations, switchgear houses, buildings and electrical installations: Renowned companies rely on SCHEIDT. And rightly so. Because we are the tailor-made solution for a perfect result.

Wahlsburg flood station

Request:

A small station was needed in the middle of a flood zone, directly on the river. A standard solution was not an option.

SCHEIDT solution:

In abgeschalter Fertigung wurde ein SCHEIDT SYSTEM NZ produziert, ein hoher separater Keller für die Station gegossen und für die Auftriebssicherheit eine neue Statik berechnet. Trotz Höhe der Station (auf Basis Kundenangaben/Hochwasserstand) erfolgte der Transport in einem Stück.

Result:

Eine hochwassersichere Betontrafostation, deren innere Komponenten selbst bei steigendem oder drückendem Wasser geschützt sind.

Here, great value is placed on accuracy and flexibility, on good work in sometimes the shortest possible time.

Special paint job Marine Den Helder

Request:

A station should be built directly on the coast, where the air has a high salt content, where hurricanes of force 12 can occur and spring tides can be expected: wind-, water- and salt-proof.

SCHEIDT solution:

SCHEIDT applied a special coating to prevent carbonisation of the station. The reinforcement was statically designed for wind force 12. Due to the elevated station construction on a footbridge, doors and ventilation grilles are higher and are therefore protected from spring tides.

Result:

SCHEIDT fertigte eine Station, die selbst schwierigsten Witterungsverhältnissen trotzt und durch ihre besondere Ausführung den speziellen Belastungen standhält.

If I want something sensible, I have to leave the euro where it belongs: in quality. Cheap can be expensive.

Kinon Aachen fire protection station

Requirement:

A station for installing very large transformers, distance to the next inhabited house: less than 5 metres! Such a short distance required special fire protection measures.

SCHEIDT solution:

Aufgrund ihrer Größe und Höhe konnten die Trafos nicht auf den Doppelboden gestellt werden – weshalb dieser weggelassen wurde, die Stellung erfolgte im Keller. SCHEIDT verkaufte die erste Station mit der ersten Außenbereich-Brandschutztür überhaupt.

Result:

Despite challenging conditions, the construction of a fire-safe station for large transformers was guaranteed at a short distance from the neighbouring building.

A building in which high voltage is present is a high-risk area. Fire barriers are proven protection and a high level of safety for the systems

Bad Oeynhausen municipal utilities

Requirement:

Sicherstellung einer gleichmäßigen, guten Wasserqualität für die Bürger der Stadt mit rund 13.800 Hausanschlüssen ans Leitungsnetz. Gefragt: Gebäude zum Einsatz für Druckerhöhungsanlage, Pumpstation, Filter- und Brunnenanlagen.

SCHEIDT solution:

Water treatment system for 30 m³/h
Water treatment system for 100 m³/h with separate control room
Pumpstation bis zu 160 m³/h inkl. NotstromaggregateIraum

Result:

Alles richtig gemacht mit SCHEIDT! Die Messergebnisse nördlich und südlich der Werre dokumentieren: keine Überschreitung der Grenzwerte gemäß Trinkwasserverordnung des Wassers, das durch mehr als 430 km unterirdische Versorgungsleitungen fließt.

The main reason why people buy from us is reliability. And the fact that there is always someone available to take care of every customer request

"Auf der Nemphe" in Frankenberg

Request:

Integration of a walk-in transformer station without a basement in the city centre.

SCHEIDT solution:

Walk-in transformer station without basement
Arc fault proof
with attractive wood panelling for seamless integration into the cityscape
Roof area as a "recreational area" for city visitors
Only the expert can see that a transformer station is hidden there

Result:

Ensuring a continuous urban power supply while optimising space utilisation without endangering pedestrian traffic.

It is the human aspect that the employees of the companies here often know the owners personally

Further application examples in practice

For the world's longest power quay, Container Terminal 4 in Bremerhaven (1681 metres long), SCHEIDT supplied the cable ducts, among other things.

Wind turbines

Delivery of 21 SCHEIDT stations for the Uetze wind farm (Lower Saxony), Total output: 31.5 MW.

Photovoltaic systems

Delivery of a 500 and 1000 kW station for two roof systems in Laimering (Bavaria), 1064.9 kWp FV output.
Delivery of an FV system for a hall roof in Tödtenried (Bavaria) with a total FV output of 494.9 kWp.

For the world's longest power quay, Container Terminal 4 in Bremerhaven (1681 metres long), SCHEIDT supplied the cable ducts, among other things.

Biogas plants

Delivery SCHEIDT SYSTEM BEK 300-650, transformer generation: 1250 kVA; Transformer own consumption: 250 kVA.

Cable ducts

Halle-Leipzig: Production and delivery of 380 cable ducts within 4 months.
Container Terminal Bremerhaven: Cable ducts for the electrical and data supply as well as energy supply points for refrigerated containers.

Photovoltaic park in Great Britain

Requirement:

To complete a photovoltaic park, the task was to develop and plan walk-in 1 and 2-room stations with the customer, including taking over the entire logistics and completion on site. Authorised station width: max. 2.50 m!

SCHEIDT solution:

1-Raum-BEK, in der Trafo/Wechselrichter/ Schaltanlage in einem geprüften System in nur einem Raum untergebracht sind (bislang einzigartig)
2-Raum-BEK als Gebäudekombination: Jede Station kommt immer dann zum Einsatz, wenn entweder die Komponenten für einen Raum zu groß werden oder bei Nichtgenehmigung aufgrund der Gebäudegröße
Gewährleistung des richtigen Zusammenfügens zu einer Kombination durch Begleitung von SCHEIDT-Fachkräfteteams

Result:

Delivery and installation of all transformer stations within a very short time for the commissioning of the photovoltaic park, output: 50 MW.

It is the expansion of electrical engineering that is driving companies forward. The most important trend for the energy market of the future!

NEK, equipped with 4.5 MVA transformer!

Requirement:

To operate a wind farm, the customer needed a transformer station with a significantly higher output and the smallest possible footprint.

SCHEIDT solution:

SCHEIDT SYSTEM NEK with 3 m width and 5 m length (low overall height), equipped with a 4.5 MVA transformer and switchgear
Reinforcement of the intermediate floor basement/station top section with special reinforcement and tested design to absorb the load-bearing capacity

Result:

Taking into account and fulfilling all customer requirements (non-accessible station building with the smallest possible footprint - also in terms of height), SCHEIDT developed a station that guarantees wind farm operation in a tested manner.

Transfer station for industrial use

Requirement:

Ensuring the transfer of energy from the power supply network to the consumer in compliance with special requirements. The special machines in use generate an overvoltage that must not enter the grid. It must also be ensured that the reactive power caused by electric motors is compensated.

SCHEIDT solution:

SCHEIDT SYSTEM BEK 300-630
Integrated MS billing measurement for direct billing with the supplier
Built-in special transformer 630 kVA
NSH distribution with 2 additional billing measurements for internal use
Equipped with compensation and mains filter systems
Customised design: with the option of subsequent connection to a wind farm

Result:

Transfer station of the highest concrete and electrical engineering quality, which shields the grid from undesirable external influences and ensures the customer/consumer a constant, demand-orientated energy flow and is flexible for future projects.
